INSTA SUB8A
| Type | 8 “active sub |
| Frequency response(-10dB) | 45Hz – 120Hz |
| Rated Power | 200W (RMS) / 800W (peak) |
| Nominal impedance | 8 ohm |
| Max SPL (@1m) | 114dB (peak) |
| Coverage (H × V) | 80° × 80° |
| LF Transducer | 8″ / Φ38mm voice coil / 200W Ferrite magnet |
| Sensitivity(1m@1W) | 85dB |
| Connectors | 2 × Binding posts |
| Dimensions (W × H × D) | 515 × 200 × 425mm (including bracket) |
| Net weight | 17kg |
